EVO SP8 Manual

EVO SP8 is an 8-channel Smart Preamp with AD/DA conversion, designed to expand an existing audio interface via ADAT.

EVO SP8 smart preamp, front three-quarter view

Key features​

  • Eight EVO microphone preamps with Smartgain
  • Two JFET instrument inputs on channels 1 and 2
  • Eight balanced analogue line outputs
  • Two optical ADAT inputs and two optical ADAT outputs
  • BNC Word Clock Input
  • Front-panel Motion UI and metering
  • Firmware updating through the rear USB-C port labelled For Updates Only

In this manual​

Start with Getting Started, then use the remaining pages as needed for connections, Smartgain, clocking, Expanded EVO Systems, rack mounting, firmware, troubleshooting, specifications, safety and warranty information.
